Description
PROD No. | DESCRIPTION | O’ALL | DEPTH | FRONT | PLATFORM | REACH | WT | TRANSPORT |
---|---|---|---|---|---|---|---|---|
HEIGHT | WIDTH | HEIGHT | HEIGHT | CUBE | ||||
(m) | (m) | (m) | (m) | (m) | (kg) | (m3) | ||
SM5-2 | Stockmate 5-2 | 1.5 | 0.83 | 0.58 | 0.61 | 2.51 | 12.5 | 0.33 |
SM6-3 | Stockmate 6-3 | 1.79 | 1.01 | 0.62 | 0.88 | 2.78 | 14 | 0.39 |
SM7-4 | Stockmate 7-4 | 2.08 | 1.18 | 0.66 | 1.17 | 3.07 | 15 | 0.45 |
SM8-5 | Stockmate 8-5 | 2.37 | 1.35 | 0.7 | 1.45 | 3.35 | 16 | 0.51 |
SM9-6 | Stockmate 9-6 | 2.64 | 1.53 | 0.74 | 1.74 | 3.64 | 17 | 0.57 |
SM10-7 | Stockmate 10-7 | 2.93 | 1.7 | 0.78 | 2.02 | 3.92 | 19 | 0.63 |
SM11-8 | Stockmate 11-8 | 3.22 | 1.88 | 0.82 | 2.3 | 4.2 | 20 | 0.69 |
