Description
Motor Specifications:
- Custom designed Cyclone model
- Engine type 4-stroke, overhead valve, single cylinder
- 3/4 keyed horizontal shaft
- Net power 4.1kW (5.5HP) at 3600 rpm
- Continuous Rated power 3.7kW (5.0HP) at 3600 rpm
- 196cc Displacement
- Unleaded fuel
- Fuel tank capacity 3.1 Litres
- Replacement cyclone filters available. 17210-ZE1-505
Blade & Cutting Specifications
- Blade size ( diameter )
- Minimum 14″ (355mm)
- Maximum 16″ (406mm)
- Blade bore diameter 25.4mm / 1″
- Depth of cut: 125mm (14″) to 145mm (16″)
- Length of cut: 500mm
- Clearance up to 200mm
Carriage Dimensions
- Length: 310mm
- Width: 440mm
Bricksaw Dimensions
Assembled
- Length: 1180 mm
- Width: 680 mm
- Height: 1560 mm
- Weight: 90kg
Packed for transportation
- Length: 1200 mm
- Width: 680 mm
- Height: 800 mm
Blade is not included. Why ? Because we want you to get the best out of your BT Bricksaw.
The type of blade you use on your bricks & blocks is important!
12 Month Warranty. Made in Australia
